M.Zuiko 12-40mm f/2.8 PRO II
OM System's f/2.8 standard zoom; 24-80 mm equivalent field of view on the OM-1 Mark II.
OM System OM-1 Mark II Review
A 20.4 MP Four Thirds body: 50 fps with AF/AE tracking (SH2), 120 fps with fixed AF (SH1), an IP53 dust and splash rating, and two SD card slots.
Disclosure: As an Amazon Associate I earn from qualifying purchases. Links to retailers on this page are affiliate links. We earn a commission on purchases made through them, at no extra cost to you. It doesn't change our verdicts.
Adventure Camera
Check price at Amazon → The Verdict
A 20.4 MP Four Thirds stacked BSI Live MOS body (17.3 x 13.0 mm) with up to 50 fps with AF/AE tracking (SH2) and 120 fps with fixed AF (SH1), two SD card slots and an IP53 rating. Its shooting modes include a 50 MP handheld High Res Shot, Live ND and Starry Sky AF.
Bird and wildlife owners single out the subject detection and tracking, and owners moving from full frame or DSLRs say they chose it to carry less. Owners of the original OM-1 describe the Mark II as a small step (see What owners report).
- Overall
- 8.4/10
- Image quality
- 7.6
- Autofocus
- 8.6
- Video
- 8.0
- Speed
- 9.1
- Handling and build
- 9.3
| Imaging | |
|---|---|
| Sensor | 20MP Stacked BSI Live MOS MFT |
| Processor | TruePic X |
| Stabilization | 5-Axis IBIS (8.5 stops with Sync IS) |
| ISO Range | 200-25,600 (exp. 80-102,400) |
| Autofocus | |
| AF Points | 1,053 Cross-type Phase Detection Points |
| AF System | AI Detection AF (Human, Animal, Bird, Vehicle) |
| Burst Speed | 120 fps (SH1, fixed AF), 50 fps (SH2, AF/AE tracking) |
| Video | |
| Max Resolution | C4K 60p / 4K 60p / FHD 240p |
| Internal Rec | 10-bit 4:2:2 (H.265) |
| Profiles | OM-Log400, HLG (Hybrid Log Gamma) |
| Video Features | Vertical Video, High Speed Movie (240fps) |
| Build & Connectivity | |
| Viewfinder | 5.76M-dot OLED EVF (0.83x mag, 120fps) |
| Screen | 3.0" Vari-angle Touch (1.62M-dot) |
| Card Slots | Dual SD UHS-II |
| Ports | USB-C (PD), Micro HDMI, Mic, Headphone, Remote |
| Weather Sealing | IP53 Rated (Dustproof & Splashproof) |
| Weight | 599g (with battery and card) / 511g (stripped) |
Maker-published figures, with source and date: Numbers & Sources below.
What We Like
- 50 fps burst with AF/AE tracking (SH2), 120 fps with fixed AF (SH1)
- IP53 dust and splash rating, freezeproof to -10°C
- Two SD card slots (UHS-II)
- Subject detection and tracking, which bird and wildlife owners single out (see What owners report)
- In-camera ND, graduated ND filter and focus stacking, which owners say they use (see What owners report)
Trade-offs
- 120 fps (SH1) only with the electronic shutter, a limited lens selection, and no slow shutter speeds or flash
- Owners of the original OM-1 describe the Mark II as a small step (see What owners report)
- A few owners report bodies that would not turn on or a blank screen (see What owners report)
- Micro HDMI (Type D), not full-size
In-Depth Performance
Image Quality & Sensor Performance
The sensor is a 20.4 MP Four Thirds stacked BSI Live MOS (17.3 x 13.0 mm). For photos other people took with it, see Sample photos.
The computational High Res Shot mode produces 50 MP files handheld or 80 MP files on a tripod. Owners say they use the in-camera ND, graduated ND filter and focus stacking features (see What owners report).
Autofocus & Tracking System
The OM-1 II has 1,053 cross-type phase-detection AF points and AI subject detection for people, animals, birds and vehicles. Bird and wildlife owners single out the subject detection and tracking (see What owners report).
OM System gives up to 50 fps with AF/AE tracking (SH2) and up to 120 fps with fixed AF (SH1). SH1 uses the electronic shutter, works only with a limited lens selection, and rules out slow shutter speeds and flash. Pro Capture mode records frames before the shutter button is fully pressed.
Video Capabilities
Internal recording goes up to C4K (4096 x 2160) and 4K (3840 x 2160) at 60p in 10-bit; High-Speed Recording is Full HD only, at up to 240 fps. OM-Log400 and HLG profiles are available.
OM System lists the maximum recording time as unlimited. Video goes out over micro HDMI (Type D).
Ergonomics & Build
The body is rated IP53 (dust- and splashproof) and freezeproof to -10°C. It has two SD card slots. OM System gives the weight as 599 g with battery and card; owners moving from full frame or DSLRs say they chose it to carry less (see What owners report).
OM System rates the BLX-1 battery at approx. 520 shots (CIPA). The viewfinder is a 5.76M-dot OLED, and the rear screen a 3.0-inch vari-angle touchscreen. A few owners report bodies that would not turn on or a blank screen (see What owners report).
Sample photos from other photographers
Photos that other people took with the OM-1 Mark II and published on Wikimedia Commons under free licences. We chose them; we did not take them. The settings under each photo come from the file's own metadata.
The numbers, and where they come from
Published by the maker
| Sensor size (maker's figure) | 17.3 x 13 mm |
|---|---|
| Effective pixels | 20.4 MP |
| Continuous shooting | 120 fps (electronic shutter, SH1 mode, limited lens selection, no slow shutter speeds or flash) |
| Battery (CIPA) | 520 shots |
| Weight with battery and card | 599 g |
| Viewfinder resolution | 5.76 million dots |
Maker figures checked on 26 Sept 2026 — maker's spec sheet. Continuous shooting, in the maker's words: Silent mode / Speed SH1: Approx. 120fps (selectable 60, 100, 120fps without blackout). *Slower shutter speeds and flash cannot be used. *Compatible lenses are limited.
Computed from those figures
| Sensor area | 225 mm² |
|---|---|
| Format factor | 2x |
| Light gathered vs 35mm | −1.9 stops |
Computed from the figures above. Pixel pitch = sensor width / pixel count across. Light gathered = log2 of the area ratio to 36 x 24 mm. Diffraction limit = the aperture at which the Airy disc diameter (2.44 x lambda x N, lambda = 550 nm) reaches two pixel pitches. Other calculators use other thresholds and so quote other numbers.
What owners report
We read 129 public posts and reviews on 23 Oct 2026: reddit.com/r/OMSystem (40), bhphotovideo.com (89). Each point below came up from at least two different people; the wording is ours.
Praised repeatedly
- Bird and wildlife owners single out the subject detection and tracking. [1][2][3][4]
- Owners moving from full frame or DSLRs chose it to carry less. [1][2][3][4]
- Owners use the in-camera ND, graduated filter and focus stacking features. [1][2][3]
Complained about repeatedly
- Owners of the original OM-1 describe the Mark II as a small step. [1][2][3][4]
- A few owners report bodies that would not turn on or a blank screen. [1][2][3]
These are public posts. We do not check whether the people who wrote them bought or used this camera.
How this score is put together
8.4 out of 10
- Image quality Weight 25% 7.6
20MP stacked Four Thirds sensor
- Autofocus Weight 20% 8.6
1053 cross-type points, subject detection
- Video Weight 20% 8.0
C4K/4K 60p 10-bit internal, Full HD up to 240p
- Speed Weight 15% 9.1
50 fps with AF/AE tracking (SH2), 120 fps only with AF fixed (SH1); the G9 II tracks at 60 fps
- Handling and build Weight 20% 9.3
8.5-stop IBIS, IP53 rating, twin UHS-II
Scored against Micro Four Thirds cameras. The overall figure is the weighted mean of the rows above — it is computed, not set by hand.
How It Compares
| Spec | OM-1 Mark II | OM-1 | Panasonic GH7 |
|---|---|---|---|
| Sensor | 20MP MFT Stacked | 20MP MFT Stacked | 25.2MP MFT |
| Video | 4K60 | 4K60 | 5.8K30 |
| AF Points | 1053 points | 1053 points | 779 points |
| Burst | 120 fps | 120 fps | 14 fps |
| IBIS | 8.5 stops | 8 stops | 7.5 stops |
| Buy | Check price at Amazon | Check price at Amazon | Check price at Amazon |
Lens options
M.Zuiko 40-150mm f/2.8 PRO
An f/2.8 telephoto zoom; 80-300 mm equivalent field of view on the OM-1 Mark II.
M.Zuiko 12-100mm f/4 IS PRO
An f/4 zoom with lens stabilisation; 24-200 mm equivalent field of view on the OM-1 Mark II.
Affiliate Disclosure
We buy our own gear or rent it. No manufacturers paid for this review. We earn a commission if you use our links, which keeps this site ad-free.
Frequently Asked Questions
OM System gives it as a 20.4 MP Four Thirds stacked BSI Live MOS sensor, 17.3 x 13.0 mm. The 2x crop gives the M.Zuiko 40-150mm f/2.8 PRO an 80-300 mm equivalent field of view. Owners moving from full frame or DSLRs say they chose it to carry less (see What owners report).
It is rated IP53 (dust- and splashproof) and freezeproof to -10°C.
Bird and wildlife owners single out the subject detection and tracking, and owners moving from full frame or DSLRs say they chose it to carry less. Owners of the original OM-1 describe the Mark II as a small step, and a few owners report bodies that would not turn on or a blank screen (see What owners report).
It produces 50 MP files handheld or 80 MP files on a tripod, from the 20.4 MP sensor. For photos other people took with the camera, see Sample photos.
SH2 shoots up to 50 fps with AF/AE tracking. SH1 shoots up to 120 fps with fixed AF; OM System lists it for the electronic shutter only, with a limited lens selection and no slow shutter speeds or flash. Pro Capture records frames before the shutter button is fully pressed.
